MECHANICAL SPECIFICATION | |
Format | 1680*992*35mm |
Weight | 18kg±3% |
Front Cover | 4.0mm high transmittance solar class |
Frame | Anodised aluminium |
Cell | 60(6*10) |
Junction Box | Protection class IP65 |
Cable | 4mm², Length 1000mm |
ELECTRICAL CHARACTERISTICS | |||
Power Class | | [W] | 285 |
Power at MPP2 | PMPP | [W] | 285 |
Short Circuit Current* | ISC | [A] | 9.29 |
Open Circuit Voltage* | VOC | [V] | 38.4 |
Current at MPP* | IMPP | [A] | 9.00 |
Voltage at MPP* | VMPP | [V] | 31.7 |
Minimum performance at standard test conditions,stc1 (power tolerance 0-3%) |
