| MECHANICAL SPECIFICATION | |
| Format | 1680*992*35mm |
| Weight | 18kg±3% |
| Front Cover | 4.0mm high transmittance solar class |
| Frame | Anodised aluminium |
| Cell | 60（6*10） |
| Junction Box | Protection class IP65 |
| Cable | 4mm², Length 1000mm |
| ELECTRICAL CHARACTERISTICS | ||||
| Power Class | | [W] | 265 | 270 |
| Power at MPP2 | PMPP | [W] | 265 | 270 |
| Short Circuit Current* | ISC | [A] | 8.95 | 9.03 |
| Open Circuit Voltage* | VOC | [V] | 37.6 | 37.8 |
| Current at MPP* | IMPP | [A] | 8.58 | 8.68 |
| Voltage at MPP* | VMPP | [V] | 30.9 | 31.1 |
| Minimum performance at standard test conditions,stc1 (power tolerance 0-3%) | ||||
