MECHANICAL SPECIFICATION | |
Format | 670*540*30mm |
Weight | 4kg±3% |
Front Cover | 4.0mm high transmittance solar class |
Frame | Anodised aluminium |
Cell | 36(4*9) |
Junction Box | Protection class IP65 |
Cable | 4mm², Length 900mm |
ELECTRICAL CHARACTERISTICS | |||
Power Class | | [W] | 50 |
Power at MPP2 | PMPP | [W] | 50 |
Short Circuit Current* | ISC | [A] | 2.95 |
Open Circuit Voltage* | VOC | [V] | 21.5 |
Current at MPP* | IMPP | [A] | 2.72 |
Voltage at MPP* | VMPP | [V] | 18.4 |
Minimum performance at standard test conditions,stc1 (power tolerance 0-3%) |
